EC1230, Φ12mm*30mm

Configuration:

With or without Hall sensor

Performance: Customized in the continuous operating range

Ball bearing: Preload

Flange: Standard frange front&back/customize the frange

Shaft: Length/Diameter/Cut face/double shaft/hollow shaft

Leadwire: PVC/Silicon/Teflon/UL No/Dimension/length

Connector: JST/MOLEX/TE

Applications:

Power Tools

Pumps

Robot

Fan&Blower

Medical Equipment

  • Specifications + Detail
  • Operating range
  • Drawing
